Features

• Ultra-High Power Rating: 1700 V / 1200 A

• Configuration: Dual IGBT

• Press-Fit Contact Technology: Enhances reliability, power cycling, and mechanical robustness.

• Low Saturation Voltage: VCE(sat) for minimal conduction losses.

• Low Switching Losses: Enables efficient operation in high-power, high-frequency designs.

• Isolated Baseplate: Ensures electrical safety and simplifies cooling system design.

• Built-in NTC Thermistor: For real-time thermal monitoring and protection.

• High Ruggedness: Excellent short-circuit and overload withstand capability.

Applications

• Traction Drives: Main propulsion inverters for electric and hybrid locomotives, high-speed trains, trams, and heavy-duty mining vehicles.

• Heavy Industrial Motor Drives: For controlling very large AC motors in mining excavators, metal rolling mills, large compressors, and marine propulsion systems.

• High-Power Wind Turbine Converters: Used in the medium-voltage converters of multi-megawatt wind energy systems.

• Medium-Voltage Drives (MVD): Core component in converters for industrial medium-voltage motor drives.

• High-Power Industrial UPS: Forms the inverter stage in megawatt-class uninterruptible power supplies for critical infrastructure like data centers and industrial plants.

Description

The FD1200R17HP4-K_B2 is an ultra-high-power dual IGBT module designed for the most demanding high-voltage and high-current applications in heavy industry and traction. With an exceptional rating of 1700V and 1200A, it represents the pinnacle of performance for megawatt-scale power conversion systems. The module is engineered for maximum efficiency and reliability, featuring a very low collector-emitter saturation voltage (VCE(sat)) and optimized low switching losses, which are critical for minimizing energy dissipation and thermal stress in high-power circuits.

A key feature is its advanced press-fit contact technology, which provides a robust, solder-free interconnection for superior power cycling capability, mechanical integrity, and long-term reliability. It includes a built-in NTC thermistor for precise temperature monitoring and protection, and a fully isolated baseplate for safe and efficient thermal management. Its industrial-grade construction ensures exceptional ruggedness, short-circuit withstand capability, and operational stability under the most extreme conditions.

INFORMATION

• Configuration
  Chopper
• Dimensions (width)
  140 mm
• Dimensions (length)
  130 mm
• Features
  200% PC, Enlarged Diode
• Housing
  IHM B
• IC(nom) / IF(nom)
  1200 A
• IC max
  1200 A
• Qualification
  Industrial, Traction
• Technology
  IGBT4 - P4
• VCE(sat) (Tvj=25°C typ)
  1.9 V
• VCES / VRRM
  1700 V
• VF (Tvj=25°C typ)
  1.65 V
• Voltage Class max
  1700 V
